DoorVent

DoorVent

A controlled air flow contributes greatly to the optimum functioning of the ventilation system. The DoorVent provides the desired amount of air flow between the different rooms of a building or dwelling.

Unlike cracks under the door, the DoorVent thereby avoids draughts and attenuates intrusive noise. The fresh air must be able to circulate freely between the different rooms indoors. So Duco developed the DoorVent, an acoustic feed-through vent that is installed in the internal doors.

Technical features
Overall width size
Overall height size
436 mm 58 mm
Installation width
436 mm 417 mm
Installation height
436 mm 48 mm
Minimum door thickness
436 mm 37 mm
Maximum door thickness
436 mm 47 mm
Air flow
436 mm 70 cm²
Dne,A open position
436 mm 32 dB(A)
Dne,Atr open position
436 mm 31 dB(A)
Dn,e,W (C;Ctr) open position
436 mm 32 (0;-1) dB
Overall width size 436 mm
Overall height size 58 mm
Installation width 417 mm
Installation height 48 mm
Minimum door thickness 37 mm
Maximum door thickness 47 mm
Air flow 70 cm²
Dne,A open position 32 dB(A)
Dne,Atr open position 31 dB(A)
Dn,e,W (C;Ctr) open position 32 (0;-1) dB


Technische eigenschappen

Ontdek alle technische eigenschappen in de technische fiche.

Caractéristiques techniques

Découvrez toutes les caractéristiques techniques dans la fiche technique.

Technical properties

Discover all the technical features in the technical datasheet.

Technische Eigenschaften

Entdecken Sie alle technischen Merkmale im technischen Datenblatt.
